| Air Source Pressure (bar) | Spring Return
Torque (N.m) |
Weight KG |
|||||||||||||||||||||||
| Model | 3.5 bar | 4 bar | 4.5 bar | 5 bar | 5.5 bar | 6 bar | 7 bar | ||||||||||||||||||
| 0° 45° 90° | 0° 45° 90° | 0° 45° 90° | 0° 45° 90° | 0° 45° 90° | 0° 45° 90° | 0° 45° 90° | 0° 45° 90° | ||||||||||||||||||
| K 0080 SR1 | 36.5 | 14.8 | 22.6 | 46.4 | 19.7 | 32.5 | 56.2 | 24.6 | 42.3 | 66.1 | 29.6 | 52.2 | 32.5 | 19.7 | 46.4 | 3.9 | |||||||||
| K 0080 SR2 | 38.2 | 14.7 | 20.9 | 48.1 | 19.7 | 30.7 | 57.9 | 24.6 | 40.5 | 67.8 | 29.6 | 50.3 | 40.5 | 24.6 | 57.9 | 3.9 | |||||||||
| K 0080 SR3 | 49.9 | 19.7 | 29.0 | 59.7 | 24.6 | 38.8 | 69.5 | 29.6 | 48.7 | 89.2 | 39.4 | 68.4 | 48.7 | 29.6 | 69.5 | 4.0 | |||||||||
| K 0120 SR1 | 55.3 | 22.4 | 34.1 | 70.2 | 29.9 | 49.1 | 85.2 | 37.3 | 64.0 | 100.1 | 44.8 | 79.0 | 49.2 | 29.9 | 70.2 | 5.6 | |||||||||
| K 0120 SR2 | 57.9 | 22.4 | 31.5 | 72.8 | 29.9 | 46.5 | 87.8 | 37.3 | 61.4 | 102.7 | 44.8 | 76.3 | 61.5 | 37.3 | 87.9 | 5.6 | |||||||||
| K 0120 SR3 | 75.5 | 29.9 | 43.8 | 90.4 | 37.3 | 58.8 | 124.0 | 52.7 | 86.7 | 159.1 | 70.2 | 121.9 | 73.8 | 44.8 | 105.4 | 5.7 | |||||||||
| K 0180 SR1 | 85.0 | 34.4 | 52.6 | 107.9 | 45.8 | 75.6 | 130.9 | 57.3 | 98.5 | 153.7 | 68.8 | 121.3 | 75.5 | 45.9 | 107.9 | 8.0 | |||||||||
| K 0180 SR2 | 89.0 | 34.3 | 48.6 | 111.9 | 45.9 | 71.5 | 134.8 | 57.3 | 94.4 | 157.8 | 68.8 | 117.4 | 94.4 | 57.3 | 134.8 | 8.1 | |||||||||
| K 0180 SR3 | 116.0 | 45.9 | 67.4 | 138.9 | 57.3 | 90.4 | 161.8 | 68.8 | 113.3 | 207.7 | 91.7 | 159.1 | 113.3 | 68.8 | 161.8 | 8.3 | |||||||||
| K 0260 SR1 | 118.9 | 48.2 | 74.0 | 151.0 | 64.3 | 106.1 | 183.1 | 80.4 | 138.3 | 215.3 | 96.4 | 170.4 | 106.1 | 64.3 | 151.0 | 10.6 | |||||||||
| K 0260 SR2 | 124.7 | 48.3 | 68.3 | 156.8 | 64.3 | 100.4 | 189.0 | 80.4 | 132.6 | 221.2 | 96.5 | 164.7 | 132.4 | 80.3 | 188.9 | 10.8 | |||||||||
| K 0260 SR3 | 162.7 | 64.4 | 94.7 | 194.9 | 80.5 | 126.9 | 227.0 | 96.5 | 159.0 | 291.3 | 128.7 | 223.3 | 158.7 | 96.4 | 226.8 | 10.9 | |||||||||
| K 0350 SR1 | 158.7 | 64.3 | 98.3 | 201.6 | 85.7 | 141.1 | 244.4 | 107.1 | 183.9 | 287.2 | 128.5 | 226.8 | 141.1 | 85.7 | 201.6 | 13.7 | |||||||||
| K 0350 SR2 | 166.4 | 64.2 | 90.7 | 209.1 | 85.7 | 133.6 | 252.0 | 107.1 | 176.3 | 294.8 | 128.5 | 219.2 | 176.3 | 107.1 | 251.9 | 13.9 | |||||||||
| K 0350 SR3 | 216.7 | 85.6 | 126.0 | 259.6 | 110.4 | 168.8 | 302.3 | 128.5 | 211.7 | 388.0 | 171.3 | 297.3 | 211.7 | 128.5 | 302.3 | 14.1 | |||||||||
| K 0630 SR1 | 285.0 | 115.3 | 176.4 | 361.8 | 153.7 | 253.3 | 438.7 | 192.2 | 330.2 | 515.7 | 230.7 | 407.1 | 253.3 | 153.8 | 361.8 | 23.3 | |||||||||
| K 0630 SR2 | 298.6 | 115.3 | 162.9 | 375.4 | 153.7 | 239.7 | 452.3 | 192.3 | 316.6 | 529.2 | 230.7 | 393.5 | 316.6 | 192.3 | 452.3 | 23.7 | |||||||||
| K 0630 SR3 | 389.0 | 153.7 | 226.2 | 465.9 | 192.3 | 303.0 | 542.8 | 230.7 | 379.9 | 696.6 | 307.6 | 533.8 | 379.9 | 230.7 | 542.8 | 24.0 | |||||||||
| K 0850 SR1 | 385.7 | 156.1 | 238.7 | 489.8 | 208.2 | 342.8 | 593.8 | 260.2 | 446.9 | 697.9 | 312.2 | 551.0 | 342.9 | 208.2 | 489.8 | 33.1 | |||||||||
| K 0850 SR2 | 404.0 | 156.1 | 220.4 | 508.1 | 208.2 | 324.5 | 612.2 | 260.2 | 428.5 | 716.2 | 312.2 | 532.6 | 428.5 | 260.2 | 612.2 | 33.6 | |||||||||
| K 0850 SR3 | 526.5 | 208.2 | 306.1 | 630.6 | 260.2 | 410.2 | 734.7 | 312.2 | 514.3 | 942.7 | 416.3 | 722.4 | 514.3 | 312.2 | 734.7 | 34.0 | |||||||||
| K 1200 SR1 | 555.0 | 224.7 | 343.6 | 704.8 | 299.6 | 493.3 | 854.7 | 374.5 | 643.2 | 1004.4 | 449.4 | 793.0 | 493.4 | 299.5 | 704.8 | 48.3 | |||||||||
| K 1200 SR2 | 581.5 | 224.7 | 317.2 | 731.3 | 299.5 | 467.0 | 881.1 | 374.4 | 616.7 | 1030.8 | 449.4 | 7664.9 | 616.7 | 374.4 | 881.1 | 49.2 | |||||||||
| K 1200 SR3 | 757.7 | 299.6 | 440.5 | 907.5 | 374.4 | 590.3 | 1057.3 | 449.4 | 740.1 | 1357.0 | 599.2 | 1039.6 | 740.1 | 449.4 | 1057.3 | 50.0 | |||||||||
| K 1600 SR1 | 732.0 | 296.1 | 452.6 | 929.5 | 394.9 | 650.1 | 1126.9 | 493.6 | 847.6 | 1324.4 | 592.4 | 1045.1 | 650.3 | 395.0 | 929.6 | 62.9 | |||||||||
| K 1600 SR2 | 742.4 | 296.3 | 442.9 | 939.8 | 395.1 | 640.4 | 1137.3 | 493.8 | 837.8 | 1334.8 | 592.6 | 1035.3 | 837.3 | 493.5 | 1136.8 | 63.3 | |||||||||
| K 1600 SR3 | 1046.3 | 418.6 | 630.6 | 1240.9 | 517.3 | 828.1 | 1438.4 | 616.0 | 1025.6 | 1833.3 | 813.4 | 1420.6 | 931.2 | 568.8 | 1344.0 | 63.8 | |||||||||
