10+ Years Research & Produce Experience
OEM & ODM, Quick Supply
Pneumaster Certificates
Features:
| Model | 3 bar | 3.5 bar | 4 bar | 4.5 bar | 5 bar | 5.5 bar | 6 bar | 7 bar | 8 bar |
| BDA 050 3P | 10.1 | 11.9 | 13.8 | 15.5 | 17.4 | 19.2 | 21.0 | 24.6 | 28.2 |
| BDA 065 3P | 20.6 | 24.3 | 27.8 | 31.5 | 35.2 | 38.9 | 42.6 | 49.9 | 57.2 |
| BDA 075 3P | 31.9 | 37.6 | 43.4 | 49.0 | 54.7 | 60.4 | 66.2 | 77.5 | 88.9 |
| BDA 085 3P | 46.9 | 55.2 | 63.6 | 72.0 | 80.3 | 88.7 | 97.1 | 113.8 | 130.6 |
| BDA 095 3P | 65.9 | 77.6 | 89.3 | 101.1 | 112.9 | 124.6 | 136.4 | 159.9 | 183.4 |
| BDA 110 3P | 86.6 | 101.9 | 117.0 | 132.2 | 147.4 | 162.6 | 177.8 | 208.2 | 238.5 |
| BDA 125 3P | 154.7 | 181.9 | 208.9 | 236.1 | 263.3 | 290.4 | 317.6 | 371.8 | 426.1 |
| BDA 140 3P | 230.3 | 270.0 | 309.6 | 349.4 | 389.1 | 428.7 | 468.4 | 547.9 | 627.2 |
| BDA 160 3P | 316.8 | 372.4 | 428.0 | 483.5 | 539.1 | 594.7 | 650.3 | 761.5 | 872.7 |
| BDA 190 3P | 502.5 | 589.1 | 675.7 | 762.3 | 849.0 | 935.7 | 1022.3 | 1195.5 | 1368.8 |
| BDA 210 3P | 701.5 | 822.5 | 943.4 | 1064.4 | 1185.3 | 1306.2 | 1427.2 | 1669.1 | 1911.0 |
| BDA 240 3P | 1088.0 | 1275.6 | 1463.2 | 1650.8 | 1838.4 | 2026.0 | 2213.6 | 2588.8 | 2964.0 |
| BDA 270 3P | 1530.1 | 1793.9 | 2057.7 | 2321.5 | 2585.2 | 2849.1 | 3112.9 | 3640.5 | 4168.1 |
| BDA 300 3P | 1968.5 | 2307.9 | 2647.3 | 2986.7 | 3326.1 | 3665.5 | 4004.9 | 4683.6 | 5362.5 |
| BDA 350 3P | 2921.1 | 3425.2 | 3928.9 | 4432.5 | 4936.2 | 5440.0 | 5943.7 | 6951.0 | 7958.5 |
| BDA 400 3P | 4451.7 | 5219.3 | 5986.8 | 6754.4 | 7521.9 | 8289.4 | 9057.0 | 10592.1 | 12127.1 |
